Description
Specification
| KOOL Handheld 3D Laser Scanner | Scan Range | 0.1-40m @10% reflectivity; 0.1-100m @90% reflectivity |
| FOV | 360°(H.)x130°(V.) optimized for data redundancy | |
| Scanner Sensor | Mixed solid-state laser with stable internal structure | |
| Mapping Method | SLAM, with realtime point cloud display | |
| Process Mode | Realtime and post-process both | |
| Scan Rate | 200,000 pts/sec (equivalent to 1.2 million pts/sec resulted from non-repetitive scanning and exclusive vari-frequency tech) | |
| Laser Class | Class-1 eye-safety | |
| Camera Lens | 2x 12MP | |
| Fieldwork Control | MapStar | |
| Data Process | AcuteLas Studio | |
| Accuracy Performance | ≤1cm relative accuracy | |
| Geo-referencing | Control points establishment for localization | |
| Power Supply | Handgrip battery, 3,150mAh, 45.36Wh | |
| Power Consumption | 23W | |
| Endurance | 150 min | |
| Data Management | TF card and Type-C | |
| Memory Capacity | 128 GB, expandable | |
| Ingress Protection | IP5X | |
| Net Weight | 1.12 kg | |
| Dimension | 111x222x33 mm | |
| Working Temperature | -20℃ to 45℃ | |
| Storage Temperature | -20℃ to 45℃ |
