RAMA2

2025 New Model

Combining advantage of Laser & Photogrammetry & 3D Modeling

đŸ“„ Data Sheet Download

Description

RAMA1

Designed to Break Cliches

A blend of imagination, ability and  flexibility

Video: How to Perform Laser Measurement

Video: How to Perform Photogrammetry Measurement

Video: How 3D Modeling Works

Video: How Dual-Camera Stakeout Works

RAMA2 is Designed, styled and engineered with a blend of bold imagination, extraordinary work ability and amazing flexibility.

There are so many no-compromise reasons to choose RAMA2, from the intelligent design of software, long-range measurement capability, diverse surveying mode offering, to the overall quality, durability, and the industry-leading reliability of the brand and its distributor lineup.

The all-new laser measurement way is 20% even more efficient than you’d get from a traditional GNSS RTK. And it kicks in the instant you press the button on controller app, to measure the target that you were difficult to reach before. Until you experience it, you won’t know what the future holds.

RAMA2’s advanced photogrammetry technology enable users to easily acquiring coordinates for hundreds of points within minutes, by using the 8MP front camera to shoot a video or some photos.

The video and photos captured by RAMA2 also can be used to process out 3D model. The data output can be used with the 3rd party designing software, also can be combined with Drone (UAV) data, such as DJI and other brands.

Let’s Experience the new way of Stakeout is A new 8MP front camera and 2MP bottom camera combining with AR technology provide precise direction and dynamic responsiveness. Let your intuition lead you to the right destination.

Specification

KOOL Handheld 3D Laser Scanner Scan Range 0.1-40m @10% reflectivity; 0.1-100m @90% reflectivity
FOV 360°(H.)x130°(V.) optimized for data redundancy
Scanner Sensor Mixed solid-state laser with stable internal structure
Mapping Method SLAM, with realtime point cloud display
Process Mode Realtime and post-process both
Scan Rate 200,000 pts/sec (equivalent to 1.2 million pts/sec resulted from non-repetitive scanning and exclusive vari-frequency tech)
Laser Class Class-1 eye-safety
Camera Lens 2x 12MP
Fieldwork Control MapStar
Data Process AcuteLas Studio
Accuracy Performance ≀1cm relative accuracy
Geo-referencing Control points establishment for localization
Power Supply Handgrip battery, 3,150mAh, 45.36Wh
Power Consumption 23W
Endurance 150 min
Data Management TF card and Type-C
Memory Capacity 128 GB, expandable
Ingress Protection IP5X
Net Weight 1.12 kg
Dimension 111x222x33 mm
Working Temperature -20℃ to 45℃
Storage Temperature -20℃ to 45℃
